xta_mysql_xa_resource.h File Reference

#include <mysql.h>
#include "xta_acquired_xa_resource.h"
#include "lixa_sw.h"

Include dependency graph for xta_mysql_xa_resource.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Data Structures
struct	xta_mysql_xa_resource_t

Functions
int	xta_mysql_xa_close (xta_xa_resource_t *context, char *xa_info, int rmid, long flags)
int	xta_mysql_xa_commit (xta_xa_resource_t *context, const XID *xid, int rmid, long flags)
int	xta_mysql_xa_end (xta_xa_resource_t *context, const XID *xid, int rmid, long flags)
int	xta_mysql_xa_forget (xta_xa_resource_t *context, const XID *xid, int rmid, long flags)
int	xta_mysql_xa_open (xta_xa_resource_t *context, char *xa_info, int rmid, long flags)
int	xta_mysql_xa_prepare (xta_xa_resource_t *context, const XID *xid, int rmid, long flags)
int	xta_mysql_xa_recover (xta_xa_resource_t *context, XID *xids, long count, int rmid, long flags)
void	xta_mysql_xa_resource_clean (xta_mysql_xa_resource_t *xa_resource)
void	xta_mysql_xa_resource_delete (xta_mysql_xa_resource_t *xa_resource)
int	xta_mysql_xa_resource_init (xta_mysql_xa_resource_t *xa_resource, MYSQL *connection, const char *name, const char *open_info)
xta_mysql_xa_resource_t *	xta_mysql_xa_resource_new (MYSQL *connection, const char *name, const char *open_info)
int	xta_mysql_xa_rollback (xta_xa_resource_t *context, const XID *xid, int rmid, long flags)
int	xta_mysql_xa_start (xta_xa_resource_t *context, const XID *xid, int rmid, long flags)

Function Documentation

int xta_mysql_xa_close	(	xta_xa_resource_t *	context,
		char *	xa_info,
		int	rmid,
		long	flags
	)

Close a MySQL resource manager

Parameters

[in,out]	context	: XTA resource context
[in]	xa_info	: null-terminated character string that may contain instance-specific information for the resource manager
[in]	rmid	: an integer assigned by the transaction manager, uniquely identifies the called resource manager instance within the thread of control
[in]	flags	: TMNOFLAGS, future usage only

Returns

a XA return code

Definition at line 265 of file xta_mysql_xa_resource.c.

References XA_OK, and XAER_RMERR.

int xta_mysql_xa_commit	(	xta_xa_resource_t *	context,
		const XID *	xid,
		int	rmid,
		long	flags
	)

Commit work done on behalf of a transaction branch

Parameters

[in,out]	context	: XTA resource context
[in]	xid	transaction identifier, XA spec
[in]	rmid	: an integer assigned by the transaction manager, uniquely identifies the called resource manager instance within the thread of control
[in]	flags	: TMONEPHASE or TMNOFLAGS

Returns

a XA return code

Definition at line 444 of file xta_mysql_xa_resource.c.

References XAER_RMERR.

int xta_mysql_xa_end	(	xta_xa_resource_t *	context,
		const XID *	xid,
		int	rmid,
		long	flags
	)

End work performed on behalf of a transaction branch

Parameters

[in,out]	context	XTA resource context
[in]	xid	transaction identifier, XA spec
[in]	rmid	an integer assigned by the transaction manager, uniquely identifies the called resource manager instance within the thread of control
[in]	flags	only TMSUCCESS and TMFAIL can be passed to a MySQL resource

Returns

a XA return code

Definition at line 338 of file xta_mysql_xa_resource.c.

References XAER_RMERR.

int xta_mysql_xa_forget	(	xta_xa_resource_t *	context,
		const XID *	xid,
		int	rmid,
		long	flags
	)

Forget about a heuristically completed transaction branch

Parameters

[in,out]	context	: XTA resource context
[in]	xid	transaction identifier, XA spec
[in]	rmid	: an integer assigned by the transaction manager, uniquely identifies the called resource manager instance within the thread of control
[in]	flags	: TMNOFLAGS, future usage only

Returns

a XA return code

Definition at line 514 of file xta_mysql_xa_resource.c.

References XAER_RMERR.

int xta_mysql_xa_open	(	xta_xa_resource_t *	context,
		char *	xa_info,
		int	rmid,
		long	flags
	)

Open a MySQL resource manager

Parameters

[in,out]	context	: XTA resource context
[in]	xa_info	: null-terminated character string that may contain instance-specific information for the resource manager
[in]	rmid	: an integer assigned by the transaction manager, uniquely identifies the called resource manager instance within the thread of control
[in]	flags	: TMNOFLAGS, future usage only

Returns

a XA return code

Definition at line 221 of file xta_mysql_xa_resource.c.

References xta_mysql_xa_resource_t::connection, xta_mysql_xa_resource_t::lssr, XA_OK, and XAER_RMERR.

int xta_mysql_xa_prepare	(	xta_xa_resource_t *	context,
		const XID *	xid,
		int	rmid,
		long	flags
	)

Prepare to commit work done on behalf of a transaction branch

Parameters

[in,out]	context	: XTA resource context
[in]	xid	transaction identifier, XA spec
[in]	rmid	: an integer assigned by the transaction manager, uniquely identifies the called resource manager instance within the thread of control
[in]	flags	: TMNOFLAGS, future usage only

Returns

a XA return code

Definition at line 409 of file xta_mysql_xa_resource.c.

References XAER_RMERR.

int xta_mysql_xa_recover	(	xta_xa_resource_t *	context,
		XID *	xids,
		long	count,
		int	rmid,
		long	flags
	)

Obtain a list of prepared transaction branches from a resource manager

Parameters

[in,out]	context	: XTA resource context
[in]	xids	: an array into which the resource manager places XIDs for list of transaction branches that are currently in a prepared or heuristically completed state
[in]	count	: the maximum number of XIDs that fit into that array
[in]	rmid	: an integer assigned by the transaction manager, uniquely identifies the called resource manager instance within the thread of control
[in]	flags	: TMSTARTRSCAN, TMENDRSCAN, TMNOFLAGS

Returns

a XA return code

Definition at line 479 of file xta_mysql_xa_resource.c.

References XAER_RMERR.

void xta_mysql_xa_resource_clean

(

xta_mysql_xa_resource_t *

xa_resource

)

Clean the properties of a MySQL XA Resource; this function must be called after xta_mysql_xa_resource_init during object deletion to avoid memory leaks

Parameters

[in,out]

xa_resource

: MySQL XA Resource object

Definition at line 191 of file xta_mysql_xa_resource.c.

References xta_xa_resource_s::act_rsrmgr_config, LIXA_RC_INTERNAL_ERROR, LIXA_RC_OK, xta_mysql_xa_resource_t::xa_resource, and xta_acquired_xa_resource_clean().

Referenced by xta_mysql_xa_resource_delete().

void xta_mysql_xa_resource_delete

(

xta_mysql_xa_resource_t *

xa_resource

)

Delete an object that represent a MySQL XA Resource

Parameters

[in]

xa_resource

: MySQL XA Resource

Definition at line 112 of file xta_mysql_xa_resource.c.

References LIXA_RC_INTERNAL_ERROR, LIXA_RC_OK, and xta_mysql_xa_resource_clean().

int xta_mysql_xa_resource_init	(	xta_mysql_xa_resource_t *	xa_resource,
		MYSQL *	connection,
		const char *	name,
		const char *	open_info
	)

Initialize the propeties of a MySQL XA resource

Parameters

[in,out]	xa_resource	: MySQL XA Resource object
[in]	connection	: to MySQL already opened by the application program
[in]	name	: unique identifier of the resource
[in]	open_info	: unique description of the connection properties like network name/IP address, port, user/schema, etc. Only the first MAXINFOSIZE characters will be kept.

Returns

a reason code

Definition at line 141 of file xta_mysql_xa_resource.c.

References xta_xa_resource_s::act_rsrmgr_config, xta_mysql_xa_resource_t::connection, lixa_iface_set_xta(), LIXA_RC_INTERNAL_ERROR, LIXA_RC_NULL_OBJECT, LIXA_RC_OK, xta_mysql_xa_resource_t::lssr, xta_mysql_xa_resource_t::xa_resource, and xta_acquired_xa_resource_init().

Referenced by xta_mysql_xa_resource_new().

xta_mysql_xa_resource_t* xta_mysql_xa_resource_new	(	MYSQL *	connection,
		const char *	name,
		const char *	open_info
	)

Create a new object to represent a MySQL XA resource

Parameters

[in]	connection	to MySQL already opened by the application program
[in]	name	: unique identifier of the resource
[in]	open_info	: unique description of the connection properties like network name/IP address, port, user/schema, etc. Only the first MAXINFOSIZE characters will be kept.

Returns

a new object or NULL in the event of error

Definition at line 69 of file xta_mysql_xa_resource.c.

References LIXA_RC_G_TRY_MALLOC_ERROR, LIXA_RC_INTERNAL_ERROR, LIXA_RC_OK, and xta_mysql_xa_resource_init().

int xta_mysql_xa_rollback	(	xta_xa_resource_t *	context,
		const XID *	xid,
		int	rmid,
		long	flags
	)

Roll back work done on behalf of a transaction branch

Parameters

[in,out]	context	: XTA resource context
[in]	xid	transaction identifier, XA spec
[in]	rmid	: an integer assigned by the transaction manager, uniquely identifies the called resource manager instance within the thread of control
[in]	flags	: TMNOFLAGS, future usage only

Returns

a XA return code

Definition at line 374 of file xta_mysql_xa_resource.c.

References XAER_RMERR.

int xta_mysql_xa_start	(	xta_xa_resource_t *	context,
		const XID *	xid,
		int	rmid,
		long	flags
	)

Start work on behalf of a transaction branch

Parameters

[in,out]	context	XTA resource context
[in]	xid	transaction identifier, XA spec
[in]	rmid	an integer assigned by the transaction manager, uniquely identifies the called resource manager instance within the thread of control
[in]	flags	only TMNOFLAGS can be passed to a MySQL resource

Returns

a XA return code

Definition at line 303 of file xta_mysql_xa_resource.c.

References XAER_RMERR.
