#include <xa.h>

Include dependency graph for xta_xid.h:

This graph shows which files directly or indirectly include this file:

Data Structures
struct	xta_xid_t

Functions
int	xta_xid_branch_qualifier_is_multibranch (const char *branch_qualifier)

int	xta_xid_branch_qualifier_set_multibranch (char *branch_qualifier)

int	xta_xid_branch_qualifier_unset_multibranch (char *branch_qualifier)

void	xta_xid_delete (xta_xid_t *xid)

xta_xid_t *	xta_xid_dup (const xta_xid_t *xid)

long	xta_xid_get_bqual (const xta_xid_t xid, char bqual)

long	xta_xid_get_formatID (const xta_xid_t *xid)

long	xta_xid_get_gtrid (const xta_xid_t xid, char gtrid)

const XID *	xta_xid_get_xa_xid (const xta_xid_t *xid)

xta_xid_t *	xta_xid_new (const char *branch_qualifier, int multiple_branches)

xta_xid_t *	xta_xid_new_from_string (const char *xid_string)

xta_xid_t *	xta_xid_new_from_XID (const XID *xid)

void	xta_xid_reset (xta_xid_t *xid)

char *	xta_xid_to_string (const xta_xid_t *xid)

Function Documentation

int xta_xid_branch_qualifier_is_multibranch ( const char * branch_qualifier )

Check if a branch_qualifier is related to a multiple branches transaction or not

Parameters

[in] branch_qualifier that must be checked

Returns: a boolean value: TRUE for multiple branches transaction

Definition at line 110 of file xta_xid.c.

Referenced by xta_transaction_branch(), xta_transaction_commit(), and xta_xid_new().

int xta_xid_branch_qualifier_set_multibranch ( char * branch_qualifier )

Set branch_qualifier to be a multiple branches transaction

Parameters

[in,out] branch_qualifier that must be checked

Returns: a boolean value: TRUE if branch_qualifier has been changed

Definition at line 138 of file xta_xid.c.

Referenced by xta_xid_new().

int xta_xid_branch_qualifier_unset_multibranch ( char * branch_qualifier )

Unset branch_qualifier to be a multiple branches transaction

Parameters

[in,out] branch_qualifier that must be checked

Returns: a boolean value: TRUE if branch_qualifier has been changed

Definition at line 219 of file xta_xid.c.

Referenced by xta_xid_new().

void xta_xid_delete ( xta_xid_t * xid )

Delete a Transaction Identifier object

Parameters

[in] xid object to delete

Definition at line 432 of file xta_xid.c.

References LIXA_RC_INTERNAL_ERROR, and LIXA_RC_OK.

Referenced by xta_transaction_delete().

xta_xid_t* xta_xid_dup ( const xta_xid_t * xid )

Create a new Transaction Identifier object duplicating the passed one

Parameters

[in] xid is the transaction identifier that must be duplicated

Returns: a new transaction identifier object or NULL in the event of an error occurred

Definition at line 385 of file xta_xid.c.

References LIXA_RC_G_TRY_MALLOC_ERROR, LIXA_RC_INTERNAL_ERROR, LIXA_RC_NULL_OBJECT, LIXA_RC_OK, and xta_xid_t::xa_xid.

long xta_xid_get_bqual	(	const xta_xid_t *	xid,
		char *	bqual
	)

This is just a wrapper of lixa_xid_get_bqual

Definition at line 569 of file xta_xid.c.

References xta_xid_t::xa_xid.

long xta_xid_get_formatID ( const xta_xid_t * xid )

This is just a wrapper of lixa_xid_get_formatID

Definition at line 575 of file xta_xid.c.

References xta_xid_t::xa_xid.

long xta_xid_get_gtrid	(	const xta_xid_t *	xid,
		char *	gtrid
	)

This is just a wrapper of lixa_xid_get_gtrid

Definition at line 563 of file xta_xid.c.

References xta_xid_t::xa_xid.

const XID* xta_xid_get_xa_xid ( const xta_xid_t * xid )

Retrieve the transaction ID in the XA standard format

Parameters

[in] xid object

Returns: a reference to the XA representation of the transaction id

Definition at line 458 of file xta_xid.c.

References LIXA_RC_INTERNAL_ERROR, LIXA_RC_NULL_OBJECT, LIXA_RC_OK, and xta_xid_t::xa_xid.

Referenced by xta_transaction_branch(), xta_transaction_commit(), xta_transaction_resume(), xta_transaction_rollback(), xta_transaction_start(), and xta_transaction_suspend().

xta_xid_t* xta_xid_new	(	const char *	branch_qualifier,
		int	multiple_branches
	)

Create a new Transaction Identifier object and generate a new unique XID

Parameters

[in]	branch_qualifier	that must be assigned to the XID (in ASCII HEX format)
[in]	multiple_branches	: boolean value: TRUE = the created transaction will span more applications, xta_transaction_branch will be called subsequently FALSE = the created transaction will not span more applications and xta_transaction_branch will not be called for this transaction

Returns: a new transaction identifier object or NULL in the event of an error occurred

Definition at line 47 of file xta_xid.c.

References LIXA_RC_G_TRY_MALLOC_ERROR, LIXA_RC_INTERNAL_ERROR, LIXA_RC_OK, LIXA_RC_STRDUP_ERROR, xta_xid_branch_qualifier_is_multibranch(), xta_xid_branch_qualifier_set_multibranch(), and xta_xid_branch_qualifier_unset_multibranch().

Referenced by xta_transaction_start().

xta_xid_t* xta_xid_new_from_string ( const char * xid_string )

Create a new Transaction Identifier object and set XID as passed by the caller

Parameters

[in] xid_string a serialized XID, see xta_xid_to_string

Returns: a new transaction identifier object or NULL in the event of an error occurred

Definition at line 291 of file xta_xid.c.

References LIXA_RC_G_TRY_MALLOC_ERROR, LIXA_RC_INTERNAL_ERROR, LIXA_RC_MALFORMED_XID, and LIXA_RC_OK.

Referenced by xta_transaction_resume().

xta_xid_t* xta_xid_new_from_XID ( const XID * xid )

Create a new Transaction Identifier object and set XID as passed by the caller. This is considered a private method because the an XTA application should not manage the XID struct directly.

Parameters

[in] xid a native XA XID
